TimeLink is the professional manufacturer of Interactive Whiteboard in the world. With the unique Surface Light
Wave technology and intuitive design, TimeLink’s interactive Whiteboard realizes 2-48 touch points freestyle interaction.
| ♦ Ultra-slim Frame width with 24 mm | ♦ High respond speed (Up to 200 fps) |
| ♦ 2/4/6/10...up to 48 touch points | ♦ High redundancy design |
| ♦ Size: 75"-150" | ♦ Easy maintenance & setup |
| ♦ Anti-dust & Anti strong light | ♦ Perfect combination with any education software |
| ♦ Palm rejection | ♦ Mounted or Floor stand (Optional） |
| ♦ Support 42 gestures( Incl. Gestures of Mac and win 10/8/7) | ♦ PCB & SKD solution (Optional) |
| Physical Specification | Standard Size | 75”-150" |
| Bezel Width | 24mm-50mm | |
| Power Supply | USB | |
| Shortcut Key | Both Sides (Optional) | |
| Temperature & Humidity | Working:-10~50℃, Storage:-20~60℃ | |
| Anti Strong Light | Still able to work under strong light (visible light intensity 14000 Lux / Infrared light intensity 3000 Lux) | |
| Standard Features | Touch Technology | Surface Light Wave |
| Touch Points | 2, 4, 6, 10 ... 48 | |
| Touch Objects | Any opaque object | |
| Report Resolution | 32767x32767 | |
| Touch Response Time | <10ms | |
| Power Consumption | <2.0W | |
| Anti-dust | Strong anti-dust ability, working even the whole board bottom was blocked by dust. | |
| Calibration | 9 points calibration | |
| Aspect ratio | 4:3, 16:9, 16:10 | |
| Accessories | Standard Accessories | USB cable 5M, touch pen, board eraser, users manual, warranty card, brackets |
| Optional Accessories | Movable floor stand, short throw projector | |
| Diagnosis Software | Support | |
| Maintenance | PCB Replacement | PCB withdrawable installation design, easy operation |
| Warranty | 1 year | |
| Cloudboard Software ( Optional ) | Input | Multi-user operation (2/4/6/10...up to 48-touch), stylus or fingers |
| Gesture Recognition | 5 gestures | |
| Teleconference | Dial up the network by Cloud ID (defined by users) | |
| Remote Teaching | Support remote teaching, remote file transfer, remote synchronization, multi-user operation & annotation in the same page simultaneously. | |
| Audio Synchronization | Support | |
| Data Synchronization | Support (bandwidth ﹤ 50KB/S) | |
| Writing Function | Support vector zooming in & out, rotating and dragging the writing letters. | |
| File/Image Format | DOC, XLS, JPG,PNG,BMP, PPT, PDF, PNG, SVG,MP4, WMA, WMV, MP3, MPG, RMVB,OP, FLV | |
| Pen type/size/color Selection | Support | |
| Document Saving | Support auto saving and manual saving | |
| Board Eraser | Smart shape recognition. Support spot, area erasing and page clearing | |
| Support OS | Windows 7 / 8/ 10, Windows Server 2003 / 2008 | |
| Software Update | Support auto-update. Free update service |
| Product Demo 1: Video: Three people manipulate pictures at the same time, and four People write 4+4=8 simultaneously. |
